Wall and Ceiling Profiles for Over Finishing

AR 261-100

Technical Specifications

Anodised, Surface Mounted Expansion Joint Wall & Ceiling Profile with screw holes.

Width:	100 mm
Depth:	12 mm \| Compatible with AR153-100 and AR106-100.
Movement Capacity:	+/-50 mm
Profile Length:	3 mt
Profile Thickness:	2 mm

EXAMPLE APPLICATIONS
