FS300-1

Back
Technical Specifications

Arfen Fire Blanket is designed as a system produced to prevent the flame, smoke and high heat transfer that will occur in the expansion joint gaps in case of fire in the building for a specified period of time. Arfen Fire Blanket is a low-weight, high-performance and easy-to-apply system with its special fireproof fabric, 7-layer internal structure consisting of fiberglass material. It consists of a special inner filling material that is not affected by thermal shock, has high heat resistance and low thermal conductivity, and also has sound insulation properties The system is approved and certified by fire resistance performance test centers in accordance with international standards.

Expansion Joint Width: 300 mm

Application Direction: Horizontal

Fire Resistance Class : A1

Fire Endurance Period: E180 (EN1366-4:2006+A1:2010)

Product Code   Expansion Joint Width     Min. & Max. Expansion Gap   Fire Resistance Class
FS300-1 300 mm  150 mm - 450 mm   E180 - EI60 - H - M50 - F - W300
